| Qty In Quote | Size D (mm) | Code | To suit | L (mm) | L1 (mm) | Z (mm) | Weight (kg) | SDR | PN |
|---|
|
|
225 | SE22517 | 200 | 232 | 55 | 75 | 1.05 | 17 | 10 |
|
|
250 | SE25017 | 250 | 286 | 55 | 75 | 1.5 | 17 | 10 |
|
|
280 | SE28017 | 250 | 337 | 55 | 75 | 2.1 | 17 | 10 |
|
|
315 | SE31517 | 300 | 337 | 55 | 75 | 3.29 | 17 | 10 |
|
|
355 | SE35517 | 350 | 369 | 55 | 80 | 3.67 | 17 | 10 |
|
|
50 | SE5011 | 50 | 67 | 41 | 60 | 0.13 | 11 | 16 |
|
|
63 | SE6311 | 50 | 67 | 41 | 80 | 0.22 | 11 | 16 |
|
|
75 | SE7511 | 80 | 97 | 43 | 75 | 0.36 | 11 | 16 |
|
|
90 | SE9011 | 80 | 97 | 43 | 75 | 0.39 | 11 | 16 |
|
|
110 | SE11011 | 100 | 122 | 43 | 75 | 0.61 | 11 | 16 |
|
|
125 | SE12511 | 150 | 178 | 48 | 75 | 1.4 | 11 | 16 |
|
|
140 | SE14011 | 150 | 178 | 48 | 75 | 1.4 | 11 | 16 |
|
|
160 | SE16011 | 150 | 178 | 47 | 75 | 1.23 | 11 | 16 |
|
|
180 | SE18011 | 200 | 232 | 55 | 75 | 1.5 | 11 | 16 |
|
|
200 | SE20011 | 200 | 232 | 55 | 75 | 1.91 | 11 | 16 |
|
|
225 | SE22511 | 200 | 232 | 55 | 75 | 1.84 | 11 | 16 |
|
|
250 | SE25011 | 250 | 286 | 55 | 75 | 2.89 | 11 | 16 |
|
|
280 | SE28011 | 250 | 337 | 55 | 75 | 4.04 | 11 | 16 |
|
|
315 | SE31511 | 300 | 337 | 55 | 75 | 3.9 | 11 | 16 |
|
|
355 | SE35511 | 350 | 369 | 55 | 80 | 4.5 | 11 | 16 |
|
|
90 | SE9017 | 80 | 97 | 43 | 75 | 0.28 | 17 | 10 |
|
|
110 | SE11017 | 100 | 122 | 43 | 75 | 0.61 | 17 | 10 |
|
|
125 | SE12517 | 150 | 178 | 48 | 75 | 1.28 | 17 | 10 |
|
|
160 | SE16017 | 150 | 178 | 47 | 75 | 1.05 | 17 | 10 |
|
|
200 | SE20017 | 200 | 232 | 55 | 75 | 1.1 | 17 | 10 |
PE100
SDR11/17
PN16/10
