| Qty In Quote | Size D (mm) | Size D2 (mm) | Code | D1 (mm) | L (mm) | L1 (mm) | Pack Qty | Weight (kg) |
|---|
|
|
25 | 20 | 392520R | 35 | 74 | 6 | 150 | 0.05 |
|
|
32 | 20 | 393220R | 44 | 79 | 10 | 150 | 0.05 |
|
|
32 | 25 | 393225R | 44 | 79 | 10 | 150 | 0.07 |
|
|
40 | 20 | 394020R | 54 | 88 | 33 | 40 | 0.071 |
|
|
40 | 25 | 394025R | 54 | 88 | 33 | 40 | 0.07 |
|
|
40 | 32 | 394032R | 54 | 88 | 13 | 80 | 0.12 |
|
|
50 | 32 | 395032R | 66 | 96 | 18 | 35 | 0.118 |
|
|
50 | 40 | 395040R | 66 | 96 | 14 | 32 | 0.12 |
|
|
63 | 32 | 396332R | 81 | 106 | 23 | 40 | 0.18 |
|
|
63 | 40 | 396340R | 81 | 106 | 19 | 40 | 0.21 |
|
|
63 | 50 | 396350R | 81 | 106 | 15 | 40 | 0.22 |
|
|
75 | 63 | 397563R | 95 | 126 | 25 | 20 | 0.4 |
|
|
90 | 63 | 399063R | 113 | 146 | 36 | 10 | 0.6 |
|
|
90 | 75 | 399075R | 113 | 146 | 32 | 10 | 0.615 |
|
|
110 | 63 | 3911063R | 140 | 184 | 71 | 8 | 0.644 |
|
|
110 | 90 | 3911090R | 138 | 173 | 38 | 8 | 0.9 |
|
|
125 | 90 | 3912590R | 152 | 180 | 40 | 8 | 0.12 |
|
|
125 | 110 | 39125110R | 156 | 201 | 73.5 | 8 | 1.3 |
|
|
160 | 90 | 3916090R | 202 | 227 | 90 | 4 | 1.6 |
|
|
160 | 110 | 39160110R | 196 | 226 | 65 | 4 | 2.2 |
|
|
180 | 125 | 39180125R | 220 | 247 | 80 | 4 | 2.6 |
|
|
200 | 160 | 39200160R | 245 | 311 | 90 | 1 | 4.15 |
|
|
225 | 160 | 39225160R | 274 | 331 | 90 | 1 | 5.24 |
|
|
250 | 160 | 39250160R | 305 | 362 | 90 | 2 | 7.1 |
|
|
250 | 200 | 39250200R | 305 | 380 | 104 | 2 | 7.68 |
|
|
250 | 225 | 39250225R | 310 | 430 | 123 | 2 | 8.45 |
|
|
450 | 400 | 39450400R | 559 | 379 | 165 | 1 | 24.26 |
|
|
500 | 400 | 39500400R | 620 | 420 | 165 | 1 | 33.02 |
|
|
500 | 450 | 39500450R | 620 | 385 | 170 | 1 | 30.71 |
|
|
560 | 400 | 39560400R | 694 | 467 | 165 | 1 | 46.26 |
|
|
560 | 450 | 39560450R | 694 | 433 | 170 | 1 | 44.11 |
|
|
560 | 500 | 39560500R | 694 | 403 | 170 | 1 | 40.57 |
|
|
630 | 400 | 39630400R | 779 | 531 | 165 | 1 | 65.79 |
|
|
630 | 450 | 39630450R | 779 | 497 | 170 | 1 | 63.8 |
|
|
630 | 500 | 39630500R | 779 | 467 | 170 | 1 | 60.44 |
|
|
630 | 560 | 39630560R | 779 | 429 | 180 | 1 | 55.42 |
|
|
160 | 125 | 39160125R | 196 | 226 | 65 | 4 | 2.8 |
|
|
315 | 200 | 39315200R | - | 414 | - | 1 | 11.6 |
|
|
315 | 225 | 39315225R | - | - | - | - | - |
|
|
315 | 250 | 39315250R | - | 382 | - | 1 | - |
PE100
SDR11
PN16
