| Qty In Quote | Mainline D (mm) | Branch Side d1 (mm) | Code | d2 (mm) | L1 (mm) | L | H | h | Weight (kg) |
|---|
|
|
710 | 315 | 39710315BS | 250 | 157 | 500 | 266 | 174 | 14 |
|
|
800 | 315 | 39800315BS | 250 | 157 | 500 | 261 | 174 | 13.5 |
|
|
900 | 315 | 39900315BS | 250 | 157 | 500 | 251 | 174 | 13.1 |
|
|
1000 | 315 | 391000315BS | 250 | 157 | 500 | 246 | 174 | 12.8 |
|
|
900 | 500 | 39900500BS | 397 | 219 | 700 | 406 | 237 | 32.6 |
|
|
1000 | 500 | 391000500BS | 397 | 219 | 700 | 396 | 237 | 31.4 |
|
|
1200 | 315 | 391200315BS | 250 | 157 | 500 | 241 | 174 | 12.3 |
|
|
1200 | 500 | 391200500BS | 397 | 219 | 700 | 378 | 237 | 29.4 |
|
|
1400 | 315 | 391400315BS | 250 | 157 | 500 | 234 | 174 | 11.9 |
|
|
1400 | 500 | 391400500BS | 397 | 219 | 700 | 363 | 237 | 28.1 |
|
|
1600 | 315 | 391600315BS | 250 | 157 | 500 | 228 | 174 | 11.7 |
|
|
1600 | 500 | 391600500BS | 397 | 219 | 700 | 352 | 237 | 27.1 |
|
|
2000 | 315 | 392000315BS | 250 | 157 | 500 | 221 | 174 | 11.3 |
|
|
2000 | 500 | 392000500BS | 397 | 219 | 700 | 337 | 237 | 25.7 |
PE100
SDR11
PN16
1300 083 326
