| Qty In Quote | Size D (mm) | Code | Centre to Face Z (mm) | R (mm) | Spigot Length L (mm) | Weight (kg) | SDR | PN |
|---|
|
|
560 | SB4556017 | 800 | 840 | 350 | 81.9 | 10 | 17 |
|
|
630 | SB4563017 | 870 | 945 | 350 | 112.4 | 10 | 17 |
|
|
710 | SB4571017 | 1390 | 1065 | 500 | 162 | 10 | 17 |
|
|
800 | SB4580017 | 1565 | 1200 | 500 | 162 | 10 | 17 |
|
|
710 | SB4571011 | 1390 | 1065 | 500 | 363 | 11 | 16 |
|
|
800 | SB4580011 | 1565 | 1200 | 500 | 518 | 11 | 16 |
|
|
50 | SB455017 | 149 | 75 | 100 | 0.2 | 10 | 17 |
|
|
63 | SB456317 | 161 | 95 | 100 | 0.2 | 10 | 17 |
|
|
75 | SB457517 | 168 | 113 | 100 | 0.4 | 10 | 17 |
|
|
90 | SB459017 | 197 | 135 | 150 | 0.6 | 10 | 17 |
|
|
110 | SB4511017 | 243 | 165 | 150 | 1.1 | 10 | 17 |
|
|
125 | SB4512517 | 253 | 188 | 150 | 1.2 | 10 | 17 |
|
|
140 | SB4514017 | 262 | 210 | 150 | 1.7 | 10 | 17 |
|
|
160 | SB4516017 | 274 | 240 | 150 | 2.2 | 10 | 17 |
|
|
180 | SB4518017 | 287 | 270 | 150 | 3 | 10 | 17 |
|
|
200 | SB4520017 | 299 | 300 | 150 | 3.7 | 10 | 17 |
|
|
225 | SB4522517 | 315 | 338 | 150 | 5 | 10 | 17 |
|
|
250 | SB4525017 | 440 | 375 | 250 | 10 | 10 | 17 |
|
|
280 | SB4528017 | 460 | 420 | 250 | 15 | 10 | 17 |
|
|
315 | SB4531517 | 535 | 473 | 250 | 17.8 | 10 | 17 |
|
|
355 | SB4535517 | 620 | 533 | 300 | 25.6 | 10 | 17 |
|
|
400 | SB4540017 | 650 | 600 | 300 | 36.3 | 10 | 17 |
|
|
450 | SB4545017 | 680 | 675 | 300 | 45.3 | 10 | 17 |
|
|
500 | SB4550017 | 760 | 750 | 350 | 62.4 | 10 | 17 |
|
|
50 | SB455011 | 149 | 75 | 100 | 0.2 | 11 | 16 |
|
|
63 | SB456311 | 161 | 95 | 100 | 0.4 | 11 | 16 |
|
|
75 | SB457511 | 168 | 113 | 100 | 0.6 | 11 | 16 |
|
|
90 | SB459011 | 197 | 135 | 150 | 0.8 | 11 | 16 |
|
|
110 | SB4511011 | 243 | 165 | 150 | 1.7 | 11 | 16 |
|
|
125 | SB4512511 | 253 | 188 | 150 | 2.3 | 11 | 16 |
|
|
140 | SB4514011 | 262 | 210 | 150 | 2.8 | 11 | 16 |
|
|
160 | SB4516011 | 274 | 240 | 150 | 3.8 | 11 | 16 |
|
|
180 | SB4518011 | 287 | 270 | 150 | 5.1 | 11 | 16 |
|
|
200 | SB4520011 | 299 | 300 | 150 | 5.6 | 11 | 16 |
|
|
225 | SB4522511 | 315 | 338 | 150 | 7.4 | 11 | 16 |
|
|
250 | SB4525011 | 440 | 375 | 250 | 13 | 11 | 16 |
|
|
280 | SB4528011 | 460 | 420 | 250 | 15 | 11 | 16 |
|
|
315 | SB4531511 | 535 | 473 | 200 | 24.9 | 11 | 16 |
|
|
355 | SB4535511 | 620 | 533 | 300 | 39.5 | 11 | 16 |
|
|
400 | SB4540011 | 650 | 600 | 300 | 48.5 | 11 | 16 |
|
|
450 | SB4545011 | 680 | 675 | 300 | 69.8 | 11 | 16 |
|
|
500 | SB4550011 | 760 | 750 | 350 | 96.3 | 11 | 16 |
|
|
560 | SB4556011 | 800 | 840 | 350 | 129.8 | 11 | 16 |
|
|
630 | SB4563011 | 870 | 945 | 350 | 174 | 11 | 16 |
PE100
SDR11/17
PN16/10
