| Qty In Quote | Size D (mm) | Code | Z (mm) | Z1 (mm) | L (mm) | Weight (kg) | SDR | PN |
|---|
|
|
450 | LS450T17 | 890 | 445 | 175 | 44 | 17 | 10 |
|
|
500 | LS500T17 | 1060 | 530 | 215 | 71 | 17 | 10 |
|
|
560 | LS560T17 | 1211 | 561 | 235 | 124 | 17 | 10 |
|
|
630 | LS630T17 | 1332 | 666 | 255 | 164 | 17 | 10 |
|
|
450 | LS450T11 | 890 | 445 | 175 | 62 | 11 | 16 |
|
|
500 | LS500T11 | 1060 | 530 | 215 | 101 | 11 | 16 |
|
|
560 | LS560T11 | 1211 | 561 | 235 | 124 | 11 | 16 |
|
|
630 | LS630T11 | 1332 | 666 | 255 | 164 | 11 | 16 |
|
|
50 | LS50T17 | 181 | 91 | 55 | 0.21 | 17 | 10 |
|
|
63 | LS63T17 | 224 | 112 | 63 | 0.33 | 17 | 10 |
|
|
75 | LS75T17 | 242 | 121 | 70 | 0.54 | 17 | 10 |
|
|
90 | LS90T17 | 290 | 145 | 79 | 0.59 | 17 | 10 |
|
|
110 | LS110T17 | 313 | 158 | 82 | 0.92 | 17 | 10 |
|
|
125 | LS125T17 | 345 | 171 | 87 | 1.53 | 17 | 10 |
|
|
140 | LS140T17 | 380 | 190 | 92 | 2.09 | 17 | 10 |
|
|
160 | LS160T17 | 401 | 200 | 98 | 2.7 | 17 | 10 |
|
|
180 | LS180T17 | 450 | 225 | 105 | 3.97 | 17 | 10 |
|
|
200 | LS200T17 | 483 | 241 | 112 | 5.37 | 17 | 10 |
|
|
225 | LS225T17 | 530 | 265 | 120 | 6.6 | 17 | 10 |
|
|
250 | LS250T17 | 575 | 287 | 130 | 9 | 17 | 10 |
|
|
280 | LS280T17 | 630 | 315 | 139 | 11.53 | 17 | 10 |
|
|
315 | LS315T17 | 690 | 345 | 150 | 17.29 | 17 | 10 |
|
|
355 | LS355T17 | 730 | 360 | 155 | 21.81 | 17 | 10 |
|
|
400 | LS400T17 | 785 | 395 | 155 | 30.55 | 17 | 10 |
|
|
20 | LS20T11 | 115 | 67.5 | 41 | 0.04 | 11 | 16 |
|
|
25 | LS25T11 | 120 | 72.5 | 41 | 0.05 | 11 | 16 |
|
|
32 | LS32T11 | 135 | 83 | 44 | 0.07 | 11 | 16 |
|
|
40 | LS40T11 | 155 | 97 | 49 | 0.13 | 11 | 16 |
|
|
50 | LS50T11 | 181 | 91 | 55 | 0.21 | 11 | 16 |
|
|
63 | LS63T11 | 224 | 112 | 63 | 0.34 | 11 | 16 |
|
|
75 | LS75T11 | 242 | 121 | 70 | 0.55 | 11 | 16 |
|
|
90 | LS90T11 | 290 | 145 | 79 | 0.78 | 11 | 16 |
|
|
110 | LS110T11 | 313 | 158 | 82 | 1.32 | 11 | 16 |
|
|
125 | LS125T11 | 345 | 171 | 87 | 2.03 | 11 | 16 |
|
|
140 | LS140T11 | 380 | 190 | 92 | 2.74 | 11 | 16 |
|
|
160 | LS160T11 | 401 | 200 | 98 | 3.54 | 11 | 16 |
|
|
180 | LS180T11 | 450 | 225 | 105 | 5.48 | 11 | 16 |
|
|
200 | LS200T11 | 483 | 241 | 112 | 7 | 11 | 16 |
|
|
225 | LS225T11 | 530 | 265 | 120 | 8.94 | 11 | 16 |
|
|
250 | LS250T11 | 575 | 287 | 130 | 11.3 | 11 | 16 |
|
|
280 | LS280T11 | 630 | 315 | 139 | 15 | 11 | 16 |
|
|
315 | LS315T11 | 690 | 345 | 150 | 22.5 | 11 | 16 |
|
|
355 | LS355T11 | 730 | 360 | 155 | 29.79 | 11 | 16 |
|
|
400 | LS400T11 | 785 | 395 | 155 | 41.51 | 11 | 16 |
PE100
SDR11/17
PN16/10
