| Qty In Quote | Size D (mm) | Code | D2 (mm) | Z (mm) | L (mm) | L1 (mm) | Pack Qty | Weight (kg) | SDR | PN |
|---|
|
|
20 | LSSF2011 | 45 | 89 | 64 | 7 | 50 | 0.06 | 11 | 16 |
|
|
25 | LSSF2511 | 58 | 86 | 65 | 9 | 20 | 0.06 | 11 | 16 |
|
|
32 | LSSF3211 | 68 | 80 | 54 | 10 | 25 | 0.06 | 11 | 16 |
|
|
40 | LSSF4011 | 73 | 85 | 57 | 11 | 25 | 0.08 | 11 | 16 |
|
|
50 | LSSF5011 | 84 | 88 | 63 | 12 | 20 | 0.13 | 11 | 16 |
|
|
63 | LSSF6311 | 100 | 102 | 69 | 14 | 12 | 0.17 | 11 | 16 |
|
|
75 | LSSF7511 | 109 | 122 | 87 | 16 | 12 | 0.3 | 11 | 16 |
|
|
90 | LSSF9011 | 128 | 138 | 101 | 17 | 12 | 0.44 | 11 | 16 |
|
|
110 | LSSF11011 | 158 | 158 | 120 | 18 | 8 | 0.68 | 11 | 16 |
|
|
125 | LSSF12511 | 158 | 158 | 123 | 25 | 4 | 0.84 | 11 | 16 |
|
|
140 | LSSF14011 | 188 | 188 | 124 | 25 | 4 | 1.3 | 11 | 16 |
|
|
160 | LSSF16011 | 212 | 212 | 133 | 25 | 6 | 1.64 | 11 | 16 |
|
|
180 | LSSF18011 | 212 | 212 | 160 | 30 | 2 | 1.87 | 11 | 16 |
|
|
200 | LSSF20011 | 268 | 268 | 132 | 32 | 2 | 2.76 | 11 | 16 |
|
|
225 | LSSF22511 | 268 | 268 | 138 | 32 | 2 | 2.97 | 11 | 16 |
|
|
250 | LSSF25011 | 320 | 320 | 130 | 35 | 2 | 4.54 | 11 | 16 |
|
|
280 | LSSF28011 | 320 | 320 | 140 | 35 | 2 | 4.93 | 11 | 16 |
|
|
315 | LSSF31511 | 370 | 370 | 150 | 35 | 1 | 6.39 | 11 | 16 |
|
|
355 | LSSF35511 | 444 | 430 | 165 | 40 | 1 | 10.4 | 11 | 16 |
|
|
400 | LSSF40011 | 495 | 482 | 182 | 40 | 1 | 14.6 | 11 | 16 |
|
|
450 | LSSF45011 | 558 | 535 | 500 | 40 | 1 | 35.54 | 11 | 16 |
|
|
500 | LSSF50011 | 615 | 585 | 500 | 50 | 1 | 46.13 | 11 | 16 |
|
|
560 | LSSF56011 | 615 | 685 | 230 | 60 | 1 | 38 | 11 | 16 |
|
|
630 | LSSF63011 | 642 | 685 | 250 | 60 | 1 | 42.3 | 11 | 16 |
|
|
50 | LSSF5017 | 88 | 82 | 79 | 12 | 20 | 0.114 | 17 | 10 |
|
|
63 | LSSF6317 | 102 | 95 | 88 | 14 | 12 | 0.17 | 17 | 10 |
|
|
75 | LSSF7517 | 122 | 106 | 70 | 16 | 12 | 0.28 | 17 | 10 |
|
|
90 | LSSF9017 | 128 | 140 | 97 | 17 | 12 | 0.4 | 17 | 10 |
|
|
110 | LSSF11017 | 158 | 160 | 111 | 18 | 8 | 0.532 | 17 | 10 |
|
|
125 | LSSF12517 | 158 | 170 | 141 | 18 | 4 | 0.64 | 17 | 10 |
|
|
160 | LSSF16017 | 212 | 200 | 157 | 18 | 6 | 1.28 | 17 | 10 |
|
|
180 | LSSF18017 | 212 | 165 | 177 | 20 | 2 | 2.22 | 17 | 10 |
|
|
200 | LSSF20017 | 268 | 185 | 133 | 24 | 2 | 2.195 | 17 | 10 |
|
|
225 | LSSF22517 | 268 | 182 | 144 | 24 | 2 | 3.535 | 17 | 10 |
|
|
250 | LSSF25017 | 320 | 205 | 148 | 36 | 2 | 4.04 | 17 | 10 |
|
|
280 | LSSF28017 | 320 | 205 | 152 | 36 | 2 | 3.42 | 17 | 10 |
|
|
315 | LSSF31517 | 370 | 225 | 166 | 41 | 1 | 5.06 | 17 | 10 |
|
|
355 | LSSF35517 | 430 | 245 | 175 | 41 | 1 | 6.31 | 17 | 10 |
|
|
400 | LSSF40017 | 480 | 275 | 180 | 49 | 1 | 8.5 | 17 | 10 |
|
|
450 | LSSF45017 | 585 | 315 | 207 | 46 | 1 | 9.48 | 17 | 10 |
|
|
500 | LSSF50017 | 585 | 325 | 225 | 46 | 1 | 8.38 | 17 | 10 |
|
|
560 | LSSF56017 | 615 | 355 | 230 | 50 | 1 | 27.5 | 17 | 10 |
|
|
630 | LSSF63017 | 685 | 355 | 250 | 50 | 1 | 30 | 17 | 10 |
PE100
SDR11/17
PN16/10
