| Qty In Quote | PE Pipe Size (mm) | Code | Flange Size | OD (mm) | PCD (mm) | ID (mm) | TH (mm) | Bolt Holes No x D (mm) | Bolt Size | Weight (kg) |
|---|
|
|
32 | GBR32DIN | 1" | 115 | 85 | 44 | 12 | 14 x 4 | M12 | 0.78 |
|
|
40 | GBR40DIN | 1 1/4" | 140 | 100 | 52 | 14 | 18 x 4 | M16 | 1.35 |
|
|
50 | GBR50DIN | 1 1/2" | 150 | 110 | 62 | 14 | 18 x 4 | M16 | 1.5 |
|
|
63 | GBR63DIN | 2" | 165 | 125 | 78 | 16 | 18 x 4 | M16 | 1.96 |
|
|
75 | GBR75DIN | 2 1/2" | 185 | 145 | 92 | 16 | 18 x 8 | M16 | 2.29 |
|
|
90 | GBR90DIN | 3" | 200 | 160 | 108 | 18 | 18 x 8 | M16 | 2.86 |
|
|
110 | GBR110DIN | 4" | 220 | 180 | 128 | 18 | 18 x 8 | M16 | 3.27 |
|
|
125 | GBR1254DIN | 4" | 220 | 180 | 140 | 18 | 18 x 8 | M16 | 2.92 |
|
|
125 | GBR1255DIN | 5" | 250 | 210 | 140 | 25 | 18 x 8 | M16 | 6.23 |
|
|
140 | GBR140DIN | 5" | 250 | 210 | 158 | 18 | 18 x 8 | M16 | 3.89 |
|
|
160 | GBR160DIN | 6" | 285 | 240 | 178 | 20 | 22 x 8 | M20 | 5.64 |
|
|
180 | GBR180DIN | 6" | 285 | 240 | 195 | 20 | 22 x 8 | M20 | 4.86 |
|
|
200 | GBR200DIN | 8" | 340 | 295 | 235 | 24 | 22 x 12 | M20 | 8.09 |
|
|
225 | GBR225DIN | 8" | 340 | 295 | 240 | 24 | 22 x 12 | M20 | 7.74 |
|
|
250 | GBR250DIN | 10" | 405 | 355 | 290 | 30 | 26 x 12 | M24 | 13.31 |
|
|
280 | GBR280DIN | 10" | 405 | 355 | 300 | 30 | 26 x 12 | M24 | 12.22 |
|
|
315 | GBR315DIN | 12" | 460 | 410 | 345 | 34 | 26 x 12 | M24 | 17.75 |
