| Qty In Quote | Size D (mm) | Code | Z (mm) | Pack Qty | Weight (kg) | SDR | PN |
|---|
|
|
500 | LS500EC11 | 160 | 1 | 10.99 | 11 | 16 |
|
|
560 | LS560EC11 | 160 | 1 | 12.85 | 11 | 16 |
|
|
630 | LS630EC11 | 160 | 1 | 17.25 | 11 | 16 |
|
|
800 | LS800EC11 | 200 | 1 | 36.34 | 11 | 16 |
|
|
1000 | LS1000EC11 | 200 | 1 | 54.6 | 11 | 16 |
|
|
160 | LS160EC17 | 120 | - | 1.71 | 17 | 10 |
|
|
180 | LS180EC17 | 128 | - | 1.74 | 17 | 10 |
|
|
200 | LS200EC17 | 138 | - | 1.82 | 17 | 10 |
|
|
225 | LS225EC17 | 148 | - | 2.3 | 17 | 10 |
|
|
250 | LS250EC17 | 129 | - | 3.26 | 17 | 10 |
|
|
280 | LS280EC17 | 139 | - | 4.44 | 17 | 10 |
|
|
315 | LS315EC17 | 150 | - | 6.17 | 17 | 10 |
|
|
355 | LS355EC17 | 164 | - | 8.88 | 17 | 10 |
|
|
20 | LS20EC11 | 51 | 50 | 0.01 | 11 | 16 |
|
|
25 | LS25EC11 | 52 | 50 | 0.01 | 11 | 16 |
|
|
32 | LS32EC11 | 54 | 1 | 0.02 | 11 | 16 |
|
|
40 | LS40EC11 | 57 | 1 | 0.03 | 11 | 16 |
|
|
50 | LS50EC11 | 63 | 1 | 0.08 | 11 | 16 |
|
|
63 | LS63EC11 | 65 | 1 | 0.1 | 11 | 16 |
|
|
75 | LS75EC11 | 80 | 40 | 0.21 | 11 | 16 |
|
|
90 | LS90EC11 | 90 | 1 | 0.26 | 11 | 16 |
|
|
110 | LS110EC11 | 98 | 1 | 0.4 | 11 | 16 |
|
|
125 | LS125EC11 | 105 | 1 | 0.57 | 11 | 16 |
|
|
160 | LS160EC11 | 120 | 1 | 1.07 | 11 | 16 |
|
|
180 | LS180EC11 | 128 | 1 | 1.8 | 11 | 16 |
|
|
200 | LS200EC11 | 138 | 5 | 1.84 | 11 | 16 |
|
|
225 | LS225EC11 | 148 | 5 | 2.5 | 11 | 16 |
|
|
250 | LS250EC11 | 129 | 4 | 3.26 | 11 | 16 |
|
|
280 | LS280EC11 | 139 | 3 | 4.46 | 11 | 16 |
|
|
315 | LS315EC11 | 150 | 2 | 6.19 | 11 | 16 |
|
|
355 | LS355EC11 | 164 | 1 | 8.91 | 11 | 16 |
|
|
400 | LS400EC11 | 179 | 1 | 12.44 | 11 | 16 |
|
|
450 | LS450EC11 | 160 | 1 | 7.47 | 11 | 16 |
PE100
SDR11/17
PN16/10
