| Qty In Quote | Size D (mm) | Code | L (mm) | R (mm) | Z (mm) | Weight (kg) | SDR | PN |
|---|
|
|
63 | MB6311 | 69 | 63 | 131 | 0.3 | 11 | 16 |
|
|
75 | MB7511 | 76 | 75 | 153 | 0.46 | 11 | 16 |
|
|
90 | MB9011 | 83 | 90 | 176 | 0.75 | 11 | 16 |
|
|
110 | MB11011 | 98 | 110 | 160 | 1.3 | 11 | 16 |
|
|
125 | MB12511 | 92 | 125 | 216 | 1.82 | 11 | 16 |
|
|
140 | MB14011 | 96 | 140 | 237 | 2.23 | 11 | 16 |
|
|
160 | MB16011 | 103 | 160 | 262 | 3.46 | 11 | 16 |
|
|
180 | MB18011 | 115 | 180 | 294 | 5 | 11 | 16 |
|
|
200 | MB20011 | 123 | 200 | 325 | 6.76 | 11 | 16 |
|
|
225 | MB22511 | 131 | 225 | 353 | 9.2 | 11 | 16 |
|
|
250 | MB25011 | 134 | 250 | 384 | 12.99 | 11 | 16 |
|
|
280 | MB28011 | 153 | 280 | 436 | 18.34 | 11 | 16 |
|
|
315 | MB31511 | 154 | 315 | 471 | 33.3 | 11 | 16 |
|
|
355 | MB35511 | 400 | 380 | N/A | 46.65 | 11 | 16 |
|
|
400 | MB40011 | 450 | 435 | N/A | 67.45 | 11 | 16 |
|
|
450 | MB45011 | 500 | 450 | N/A | 90.38 | 11 | 16 |
|
|
500 | MB50011 | 500 | 450 | N/A | 111.56 | 11 | 16 |
|
|
63 | MB6317 | 69 | 63 | 130 | 0.2 | 17 | 10 |
|
|
75 | MB7517 | 76 | 75 | 152 | 0.34 | 17 | 10 |
|
|
90 | MB9017 | 83 | 90 | 173 | 0.52 | 17 | 10 |
|
|
110 | MB11017 | 98 | 110 | 193 | 0.95 | 17 | 10 |
|
|
125 | MB12517 | 92 | 125 | 216 | 1.34 | 17 | 10 |
|
|
140 | MB14017 | 96 | 140 | 237 | 1.6 | 17 | 10 |
|
|
160 | MB16017 | 103 | 160 | 260 | 2.45 | 17 | 10 |
|
|
180 | MB18017 | 115 | 180 | 290 | 3.4 | 17 | 10 |
|
|
200 | MB20017 | 123 | 200 | 320 | 4.61 | 17 | 10 |
|
|
225 | MB22517 | 131 | 225 | 350 | 6.43 | 17 | 10 |
|
|
250 | MB25017 | 134 | 250 | 382 | 9.83 | 17 | 10 |
|
|
280 | MB28017 | 153 | 280 | 436 | 13.5 | 17 | 10 |
|
|
315 | MB31517 | 154 | 315 | 465 | 19.35 | 17 | 10 |
|
|
355 | MB35517 | 400 | 380 | N/A | 30.62 | 17 | 10 |
|
|
400 | MB40017 | 450 | 435 | N/A | 47.54 | 17 | 10 |
|
|
450 | MB45017 | 500 | 450 | N/A | 61.27 | 17 | 10 |
|
|
500 | MB50017 | 500 | 450 | N/A | 75.45 | 17 | 10 |
PE100
SDR11/17
PN16/10
