| Qty In Quote | Size D (mm) | Code | L (mm) | Z1 (mm) | Z2 (mm) | LE (mm) | Weight (kg) | SDR | PN |
|---|
|
|
40 | LS40MJ11 | 185 | 85 | 120 | 57 | 0.16 | 11 | 16 |
|
|
50 | LS50MJ11 | 223 | 78 | 145 | 60 | 0.29 | 11 | 16 |
|
|
63 | LS63MJ11 | 254 | 80 | 164 | 63 | 0.47 | 11 | 16 |
|
|
75 | LS75MJ11 | 284 | 100 | 185 | 70 | 0.69 | 11 | 16 |
|
|
90 | LS90MJ11 | 321 | 111 | 213 | 82 | 1.15 | 11 | 16 |
|
|
110 | LS110MJ11 | 390 | 125 | 230 | 85 | 1.97 | 11 | 16 |
|
|
125 | LS125MJ11 | 412 | 128 | 277 | 90 | 2.86 | 11 | 16 |
|
|
160 | LS160MJ11 | 503 | 160 | 300 | 105 | 5.22 | 11 | 16 |
|
|
180 | LS180MJ11 | 578 | 191 | 394 | 110 | 8.59 | 11 | 16 |
|
|
200 | LS200MJ11 | 630 | 215 | 430 | 115 | 11.35 | 11 | 16 |
|
|
225 | LS225MJ11 | 692 | 220 | 475 | 350 | 15.79 | 11 | 16 |
|
|
250 | LS250MJ11 | 729 | 240 | 507 | 387 | 20.13 | 11 | 16 |
|
|
280 | LS280MJ11 | 1000 | 260 | 650 | 440 | 30.2 | 11 | 16 |
|
|
315 | LS315MJ11 | 1100 | 280 | 700 | 497 | 42.2 | 11 | 16 |
|
|
63 | LS63MJ17 | 254 | 80 | 164 | 63 | 0.34 | 17 | 10 |
|
|
75 | LS75MJ17 | 284 | 100 | 185 | 70 | 0.5 | 17 | 10 |
|
|
90 | LS90MJ17 | 321 | 111 | 213 | 82 | 0.84 | 17 | 10 |
|
|
110 | LS110MJ17 | 390 | 125 | 230 | 85 | 1.53 | 17 | 10 |
|
|
125 | LS125MJ17 | 412 | 128 | 277 | 90 | 2.13 | 17 | 10 |
|
|
160 | LS160MJ17 | 503 | 160 | 300 | 105 | 3.99 | 17 | 10 |
|
|
180 | LS180MJ17 | 578 | 191 | 394 | 110 | 6.47 | 17 | 10 |
|
|
200 | LS200MJ17 | 630 | 215 | 430 | 115 | 8.58 | 17 | 10 |
|
|
225 | LS225MJ17 | 692 | 220 | 475 | 350 | 11.92 | 17 | 10 |
|
|
250 | LS250MJ17 | 729 | 240 | 507 | 387 | 14.84 | 17 | 10 |
|
|
280 | LS280MJ17 | 1000 | 260 | 650 | 440 | 30.2 | 17 | 10 |
|
|
315 | LS315MJ17 | 1100 | 280 | 700 | 497 | 42.2 | 17 | 10 |
PE100
SDR11/17
PN16/10
